MIPI CSI-2 Camera Module

e-con Systems® offers high-quality MIPI CSI-2 camera modules specifically designed for diverse embedded vision applications. Our MIPI cameras provide exceptional performance with features such as global shutter/rolling shutter, high resolution ranging from 2.0 MP to 20 MP, high frame rates, excellent NIR performance, and more.

We continually integrate the latest image sensors from industry-leading manufacturers to ensure our camera modules remain at the forefront of technology. Our current range includes advanced sensors from Sony STARVIS™/Pregius™, onsemi™, and OmniVision®.

Our cameras are compatible with the most popular processor boards and can be easily connected via the MIPI CSI-2 interface. The interoperation is thoroughly tested and proven with many platforms for various customers. Their seamless integration with popular platforms such as NVIDIA® Jetson™ makes them ideal for a wide range of imaging applications, including: Autonomous mobile robots, Point-of-care diagnostic devices & life science equipment, Fundus cameras, Autonomous shopping systems, Smart traffic devices, Automated sports broadcasting devices, Precision agriculture.

Sony Camera Modules
Know More

onsemi Camera Modules
Know More

OmniVision Camera Modules
Know More
Camera customization

Customization
Know More
Camera customization

Evaluation platform
Know More

Wide Selection of Sensors

Resolution Image Sensor
20.0 MP AR2020
18.0 MP AR1820
16.0 MP IMX298
13.0 MP AR1335 / AR1335M
12.3 MP IMX477 / IMX412
8.0 MP IMX715 / IMX415 / IMX585 / IMX485 / AR0830 / AR0821 / IMX317
5.0 MP IMX335 / IMX264 / IMX568 / AR0521 / AR0522 / OV5640 /
3.4 MP AR0330
3.0 MP ISX031 / AR0341
Full HD IMX462 / AR0234 /
2.0 MP IMX327 / IMX290 / OV2312 / OV2311 / AR0230AT / AR0233AT

Given below are some of the other highlights of e-con’s camera modules:

  • Latest CMOS sensors: Sony STARVIS/Pregius, onsemi, and OmniVision
  • Resolutions: 2.0 MP to 20MP with high frame rates.
  • Interfaces: MIPI CSI-2, Parallel, GMSL1, GMSL2, FPD Link III, GigE and USB
  • Plug-and-play dev system for quick proof-of-concept building.
  • Warranty and long-term availability: 3-year warranty and 8-10 years lifetime support with an average MTBF of 8 years
  • Compatible with all popular processors: NVIDIA® Jetson™ Dev Kits, NXP Dev Kits, Texas Instruments® Dev Kits, Qualcomm® Dev Kits, Google Coral Dev Board, Rockchip Dev Kits, Raspberry PI 4, etc.
  • Application Software: Demo sample application with source code.
  • Camera Driver: V4L2 Linux driver with source code.
  • Features: Compact camera modules, NIR, monochrome, global shutter, low light, HDR, RGB-IR, ToF (Time of Flight), autofocus, digital zoom, image binning, multi-camera synchronization with external trigger & 360-degree stitching, and more.
