Almach - AM3703 / DM3730 Development Board

eSOM3730 Reference Design

• eSOM3730 - DM3730 Computer on Module
• 1. TI’s ARM® Cortex™-A8 DM3730 Processor
  2. TMS320C64x+™ DSP@1GHz
  3. 32 bit 512MB LPDDR SDRAM
  4. 8 bit 1GB NAND flash
  5. Power Management IC
  6. Audio Codec
  7. RTC
• Display
• 1. DVI Interface
  2. LCD module with Touch screen (7” TFT - Supports 800x480)
• Connectivity
• 1. Wi-Fi 802.11 b/g/n/a & Bluetooth Classic and BLE v4.1
• Serial Ports
• 1. 2 RS232
• USB
• 1. 1 USB Host (2.0)
  2. USB OTG
• Digital Video
• 1. 8MP MIPI Camera, 5 MP HD Camera and 1.3 MP Custom Lens Camera (add-on module)
• Miscellaneous
• 1. I2C
  2. SPI
• SD/MMC Card Support
• 1 Wire Interface
• 2 Channel 10 bit ADC
• Upto 50 User Configurable GPIOs
• Aux-In, Headset and MIC Interface
• Dimension - 118.29 mm (L) X 75 mm (B)
• Power Supply: 5V / 3A
• Supporting Operating Systems
• 1. Windows Embedded Compact 2013 / WEC7 / WindowsCE 6.0
  2. Linux Kernel: 3.13.0

Download Almach - DM3730 Development Board Documents:

  Almach Hardware and Software documents

Almach - DM3730 Development Kit Contents:

Add on Boards:

5.0 MP Camera Board (ACC-3730-5640CAM)

ACC-3730-5640CAM is an Add on board to Almach - DM3730 RDK to evaluate e-CAM52A_5640_MOD, a 5MP Autofocus Camera Module based on OV5640 image sensor.

User Manual

1.0 MP Camera Board with S-Mount Lens (ACC-3730-CU10633CAM)

User Manual

USB hub and Ethernet Board (ACC-3730-ETHUSB)

ACC-3730-ETHUSB is an Add on board to Almach - DM3730 RDK. The board has one type B USB2.0 port for upstream connectivity and two type A USB2.0 downstream ports. An RJ45 jack with integrated magnetics provides 10/100 Ethernet connectivity through the upstream USB port.

User Manual

OEM Customization

You can contact sales@e-consystems.com for customization of the Almach Board
