e-CAM87_CUMI585_MOD - 4K Sony Starvis 2 IMX585 Ultra Low-Light Camera Module

• Key features:
• • Frame Rate: 8MP (4K) at 90 fps
    Refer Datasheet for complete frame rate details.
  • Output format: YUV
  • High-speed MIPI CSI-2 interface
  • Frame sync
  • CS-mount interchangeable lens holder for flexibility to choose a lens as per application requirements
  • Small form-factor
• Sensor features:
• • Sensor: IMX585 from Sony® Starvis 2
  • Focus Type: Fixed focus
  • Sensor Resolution: 8MP
  • Chroma: Color
  • Shutter type: Electronic Rolling Shutter
  • Optical Format: 1/1.2"
  • Output Format: YUV
  • Pixel size: 2.9μm x 2.9μm
  • Sensor Active Area: 3856 (H) x 2180 (V)
  • Array Size: 3856 (H) x 2180 (V)
  • Lens Holder: CS-Mount
  • FOV: TBD
• Electrical & Mechanical:
• • Operating Voltage: 3.3 V +/- 5%
  • Operating Temperature Range: -30°C to 70°C
  • Power requirements: TBD
  • Size in mm (l x b): 30 x 30 mm
• Miscellaneous:
• • Compliance: RoHS
• Launched on:

   Datasheet

e-CAM87_CUMI585_MOD Product Specification

Supported Platform	Purchase
NVIDIA Jetson AGX ORIN/ AGX XAVIER
NVIDIA Jetson ORIN NX / ORIN NANO
Qualcomm Robotics QRB5 Kit



ee-CAM87_CUMI585_MOD - Customization for other Application Processor platforms:

e-con provides customization for e-CAM87_CUMI585_MOD on any application platform as per customer requirements.

e-CAM87_CUMI585_MOD – Customization

e-con provides customization for the following requirements:

• PCB form-factor customization for any shape, connector and orientation
• Lens holder customization
• For C/CS mount lens holder
• Driver development for any OS: Linux, Android
• Interfacing with any Application Processor: NXP i.MX8 Series, NVIDIA Jetson Xavier NX, AGX Xavier, Nano and any other processor
• Interfacing with any Application Processor: NXP i.MX8 Series, NVIDIA Jetson Xavier NX, AGX Xavier, Nano and any other processor camerasolutions@e-consystems.com for customization requirements.
