NileCAM81 is a 4K HDR GMSL 2 camera based on a 1/1.7-inch AR0821 sensor with a large pixel size. This HDR camera has a high-performance onboard ISP that comes with auto exposure and auto white balance functions, which provide the best possible image output
Also, this 4K AR0821 camera has an M12 lens holder which offers customers an opportunity to use the lens of their choice. NileCAM81 is an NVIDIA Jetson camera which can be connected to both NVIDIA Jetson AGX Xavier and NVIDIA Jetson AGX Orin using GMSL 2 interface.
This GMSL camera streams high frame rate uncompressed video data of HD at 60 fps, FHD at 60 fps, and 8MP at 16 fps up to a distance of 15 meters with very low latency.
Refer
Datasheet for complete frame rate details.
- Key features:
-
- Frame Rate: Streams 8MP @ 16 fps & Full HD @ 60 fps
ReferDatasheet for complete frame rate details.
- Output format: Uncompressed UYVY format
- S-mount lens holder for flexibility to choose a lens as per application requirements
- Lightweight, versatile, and portable design
- Frame Rate: Streams 8MP @ 16 fps & Full HD @ 60 fps
- Interface:
-
- Interface: GMSL2™
- Connector: FAKRA connector
- Cable Length: 15m
- Sensor features:
-
- Sensor: AR0821 from onsemi®
- Focus Type: Fixed focus
- Sensor Resolution: 8MP
- Chroma: Color
- Shutter Type: Electronic Rolling Shutter
- Optical Format: 1/1.7"
- Output Format: Uncompressed UYVY
- Pixel Size: 2.1μm x 2.1μm
- Sensor Active Area: 3848H x 2168V
- Array Size: 3848H x 2168V
- Responsivity: 15.4 Ke-/luxsec
- SNR: 41.8 dB
- Dynamic Range: Max upto 100 dB
- Holder: M12 (S-Mount)
- FOV: 120°(D), 104.8°(H), 58.7°(V) (with the lens provided by e-con)
- Electrical & Mechanical:
-
- Operating Voltage: 12V+/- 250mV with +/- 5% tolerance
- Operating Temperature Range: -30°C to 70°C
- Deser Board Typical Power Consumption : 1.13W
- NileCAM81 Module Typical Power Consumption : 2.496W (For each camera)
- Typical power consumption: 1.13W
- Size in mm (l x b): 30 x 30 mm
- Miscellaneous:
-
- Compliance: RoHS
- Launched on:
| Part No | Supported Platforms |
Sample Price (1 Unit) |
Purchase |
|---|---|---|---|
NileCAM81_CUOAGX
 Kit Contents
|
NVIDIA® Jetson AGX Orin™/ AGX Xavier™ Dev Kit |
|
|
NileCAM81_CUNXKit Contents
|
NVIDIA® Jetson Xavier™ NX Dev Kit |
- |
|
ARM Based SolutionKit Contents
|
STEVIE Carrier and Dev Kit |
- |
|
| ARM Based Solution | Solectrix's proFRAME Base Board 3.0 PCIe | - |
|
| NileCAM81 | AAEON's BOXER-8645AI | - |
|
| NileCAM81 | Neousys NRU-51V+ Kit (Jetson Orin NX - 8GB) | - |
|
ARM Based Solution-Solectrix's proFRAME Base Board 3.0 PCIe
NileCAM81-AAEON's BOXER-8645AI
NileCAM81-Neousys NRU-51V+ Kit (Jetson Orin NX - 8GB)
NileCAM81 - Customization for other Application Processor platforms:
e-con Systems® provides camera driver development, customization and porting services for NileCAM81 on any application platform as per customer requirements.
NileCAM81 - Customization
e-con provides customization, development and porting services for the following requirements:
- IP rated (IP67) enclosure and IP rated (IP67) cables for rugged applications.
- Length of the co-axial cable
- Change of lens to meet your FOV and other requirements
- Support for other NVIDIA® Jetson™ platforms as well as carrier boards from other vendors built using NVIDIA platforms
- Support for other processor platforms
- Camera and features customization based on specific requirements. Please contact camerasolutions@e-consystems.com for customization requirements.
